Mould Flow Analysis

Mould-Flow Analysis



Plastic flow simulation in 3D is used to detect part war page, sink mark, fill time, pressure and other useful information before building the mold. Mould-Flow Plastic Insight software is a specially developed analysis software that enables a plastic flow simulation in 3D.



Besides giving the customers a realistic perspective on the overall mould design, it also acts as a means to detect:



  • Part deflection in X,Y & Z direction
  • Weld line
  • Sink marks
  • Fill time
  • Injection Pressure
  • Filling condition for 2K Over-molding
  • Filling condition between metal and plastic over-molding
  • Material fiber orientation
  • Shear rate
